FM13UF011X

2.1 Introduction

UF011X is an UHF Tag Chip IC developed by Fudan Microelectronics Company. The chip is inaccordance with EPC Global Class1 Gen2V2 and ISO/IEC 18000-63(TypeC). UF011X has dualdifferential RF ports. Omni-directional tag can be reliazed with this chip and an appropriate antenna

With the industry-leading RF Performance, the UF011X is particularly well suited for inventorymanagement applications, supply chain management, personnel or vehicle identification, librarymanagement, airline luggage tracking, intelligent manufacturing and other fields

2.2 Product Features

2.2.1 Contactless Interface

EPC Global Class1 Gen2V2 & ISO/IEC 18000-63 compliantFrequence Range: 840~960MHz

Anti-Collision -21dBm

Read sensitivity -23dBm

Write sensitivity

Data rates:

Forward link 40~160Kbits/s

Reverse link 5~640Kbits/s

2.2.2 NVM Memory

EPC memory: 128 bits, extensible to 528 bits;

User memory: 512 bits

TID memory: 96bits

Reserved memory: 64bits, include 32bits Access password and 32bits Kill password

Endurance: 100,000 cycles

Data retention: 50 years

2.2.3 Security Features

96-bit Unique Tag Identifier (TID), factory locked, read only

Password verification function

Lock command

Kill command

2.2.4 Features

Backscatter strength configurable

Memory erase/write speed configurable

Product Status Flag(PSF) function

Parallel Encoding function

Ultra reliable data reading function, invoid sending back wrong EPC, TID, or User data

Fast Initialization mode
