FM11NT082C

2.2 Features

2.2.1 Contactless Interface

 ISO/IEC14443-A compatible

 Field frequence: 13.56MHz

 Two channel mode: ISO14443-3 mode、ISO14443-4 mode

 Data rates: 106Kbps

 16bit CRC for data integrity

 7 bytes UID, anti-collision cascade level 2

 Fast anti-collision

 Fast data initialization

 Energy harvesting function

2.2.2 Contact Interface

 Zero standby power consumption

 Operating voltage for contact interface: 2.2V~3.6V

 Contact interface: I2C

 Data rate for I2C: up to 1Mbps

2.2.3 Dual Interface

 Shared 32 bytes FIFO for dual interfaces

 Dual interface arbitration:

 first come first served

 contact interface first

 contactless interface first

 no priority

 Switching between NT mode and NC mode temporarily by writing register

 Switching between NT mode and NC mode fixedly by writing EEPROM configuration word

2.2.4 EEPROM

 8K bits EEPROM totally

 888 bytes available for user application

 Endurance: 1,000,000 cycles

 Data retention: 20 years

2.2.5 Security Features

 Manufacturer programmed 7 bytes UID

 CC area is OTP which only support one time written and the data can not be reversed

 Read-only lock function of the storage area

 Security certification based on algorithm

 Active silence function of the NFC interface

 Secure user data area's access authority can be controlled by the algorithm and it's size can be adjusted after authenticated by the algorithm
