FM13UF011E

2.1 Introduction

UF011E is an UHF Tag Chip IC developed by Fudan Microelectronics Company. The chip is in accordance with EPC Global Class1 Gen2V2 and ISO/IEC 18000-63(TypeC).

With the industry-leading RF Performance, the UF011E is particularly well suited for inventory management applications, supply chain management, personnel or vehicle identification, library management, airline luggage tracking, intelligent manufacturing and other fields.

2.2 Product Features

2.2.1 Contactless Interface

Frequence Range: 840~960MHz

EPC Global Class1 Gen2V2 & ISO/IEC 18000-63 compliant

Anti-Collision

Read sensitivity -24dBm

Write sensitivity -23dBm

Data rates:

Forward link 40~160Kbits/s

Reverse link 5~640Kbits/s

2.2.2 NVM Memory

EPC memory: 128 bits, extensible to 528 bits;

User memory: 512 bits

TID memory: 96bits

Reserved memory: 64bits, include 32bits Access password and 32bits Kill password

Endurance: 100,000 cycles

Data retention: 50 years

2.2.3 Security Features

96-bit Unique Tag Identifier (TID), factory locked, read only

Password verification function

Lock command

Kill command

2.2.4 Features

Backscatter strength configurable

Memory erase/write speed configurable

Product Status Flag(PSF) function

Parallel Encoding function

Ultra reliable data reading function, invoid sending back wrong EPC, TID, or User data

Fast Initialization mode
