FM13HF02N is primarily designed for intelligent label applications such as libraries, product authentication in different industries such as pharmaceutical, medical devices and alcohol, as well as production management in different areas of the industry. This IC is the Second generation of a product family of smart label ICs based on the ISO standards ISO/IEC 15693 and ISO/IEC 18000-3 which has enhanced RF performance and reliability of EEPROM. Please consult us for more documents.
1.2 Features
1.2.1 RF Interface
ISO/IEC 15693
Contactless transmission of data and supply energy (no battery needed)
Operating distance: up to 1.5 m (depending on various parameters as e.g. field strength and antenna geometry)
Operating frequency: 13.56 MHz
Fast data transfer: up to 53 Kbit/s
High data integrity: 16-bit CRC, framing
True anticollision
Password protected Electronic Article Surveillance (EAS)
Password protected Application Family Identifier (AFI)
Data Storage Format Identifier (DSFID)
Additional fast anticollision read
Write 2 Block is supported
1.2.2 Security
Unique identifier for each device, UID is unchangeable.
Lock mechanism for each user memory block (write protection)
Lock mechanism for DSFID, AFI, EAS
Password (32-bit) protected EAS and AFI functionality
Password (32-bit) protected Label Destroy
1.2.3 Applications
Libraries
Item level tagging in pharmaceutical supply chains
Counterfeit protection for consumer goods
Industrial applications
Asset and document tracking
EEPROM
2k bits of total memory, divided in 64 blocks (4 bytes each)
Data retention of 50 years
Write endurance 100000 cycles
