Model : ZXRHF0013
Material ; PVC , ABS or PET etc
Frequency : 13.56Mhz
Chip : NXP MIFARE DESFire Light
Size: 85.5*54mm , 0.84mm thickness
Color : offset printing full color or white without printing
Certificate ;RoHS
MOQ :1000pcs
Free samples testing is available
Wide range of application:
RFID has wide application: Highway tolls, Car parking, Pigeon ring, Animal ear tag, Hotel card, Restaurant
consumption, Library card, Staff photo id card, Patrol, Fairground, Electronoic bills, Metro Card, Bus
card, Freight transport, Bath center, swimming tool and hot spring center membership card, IT equipment
management, Internet bar. We are specializing in NXP DESFire Light rfid card with full color printing for you .
Statement: Pictures above only show the product , the intellectual property rights of the logo owned by their trademark companies.
NXP's MIFARE DESFire Light is a contactless IC for easy integration into new and existing system .it predefined file system and total available memory of 640Bytes (equivalent to MIFARE Classic® with 1kB ) . Compatible with MIFARE®DESFire® EV2 also lets developers prmote their services on NXP's APPXplorer ,a collaboration platform that creates an App Store-like experience on smart cards . MIFARE DESFire light can be used in various contactless applications such as access management , event ticketing , transport ticketing , account based services , gaming and loyalty cards .You also can ask us to print with full color , serial number , hot-stamping , barcode ,etc . Free samples testing is available .
| Product | Transport Ticketing RFID NXP DESFire Light Chip Card |
| Material | PVC, ABS, PET |
| Size | Stander size(credit card size):85.5*54*0.84mm or customized |
| Surface Finishing | Glossy/Matte/Frosted/Transparent |
| Printing | thermotransfer , offset full color printing , silkscreen |
| Chips Option | NXP MIFARE DESFire Light |
| Memory | 640 byte |
| Mechanical Stability (Bending ,Torsion) | according to ISO 14443A |
| Operating Temperature | -25°C to +50°C (according to ISO 7810) |
| Storage Temperature | -25°C to +50°C (according to ISO 7810) |
| Operating Frequency | 13.56MHz |
| Typical programming cycles(at +25°C) | 100,000 |
| Data retention time (at +55°C ) | > 10 years |
| Reading distance | 3-8cm |
| Personalization | Serial number, barcode, magnetic stripe, QR code, encoding, etc |
| Package | In smaller white box, then in carton |
| Shipment | By Express, by air, by sea |
| Application | event tickets , hotel card ,door control access ,transportation ,etc .. |
Memory Organization
• 640 bytes user memory, equivalent to available user memory on legacy MIFARE Classic 1 kB product
• Data retention of 10 years and write endurance of minimum 200.000 cycles
• File system compliant to ISO/IEC 7816-4 with one predefined Directory File (DF) and a set of Elementary Files (EF) – Three standard data files, one with 32 bytes and two with 256 bytes – One cyclic record file of 4 records of each 16-byte record size – One value file for value operations including upper and lower limits – Optional Transaction Message Authentication Code (TMAC) file for transaction protection • File system compliant with MIFARE DESFire EV2 file system
• User configurable file naming enabling compatibility to legacy systems and NFC Type 4 Tag compliant configurations
TARGET APPLICATIONS
• Access management
• Event ticketing
• Transport ticketing
• Account based services
• Electronic voucher
• Gaming
• Loyalty cards
Why Chose US
1: We have our own factory and avoid any reseller for saving cost and directly benifits for customers
2: All RFID products we have approved testing certificates and experienced to ship to USA , Europe ,South America ,Africa ,and Asia areas .
3: Strictly in quality control and excellence in printing
FAQ
1: Would you are manufacturer or reseller for these kind of RFID products
- We are manufacturer in Shenzhen city of China and our headquater is card factory for 17 years experience and also have invested RFID / NFC labels factory .
2: Would you manufacture another rfid chip cards
- Yes , we are also producing many kinds of rfid chip in now popular rfid market , widely use for e-payment , door control access , hotel management , hospital , etc .
3: How about your export experience for RFID products
- We have worked with USA , Europe , South America , Asia customers and all products are working good after we get feedbacks from our clients
4: How about your payment term
- We can accpet TT , Western Union , Paypal or L/C ,it will depend on quantites of projects
5: Normally production time or leadtime
- 10-12 working days and some special complicated rfid products will fix leadtime with our engineers .
6: How about shipping
- We can arrange courier such as DHL , FedEx , UPS or TNT , seafreight and truck ,etc . It will depend on customer 's requested and trade term in contract .
7: What the difference with RFID and NFC
- RFID is widely technology than NFC and includes LF ,HF and UHF , NFC only for 13.56MHz chips and specailizing in shorter reading distance in e-payment .
8: What else we should provide before ordering
- You can send us vector ( not only jpg picture ) file such as Adobe Illustrator , PSD or PDF we can re-edit file and fonts inside for our printing publish and also should
tell us how about your rfid products application , quantities , frequency , chips etc if we can get full information can help us to make right price for you and comeptitive
9：Would you offer free samples
- You can ask for free samples for testing and shipping cost collection , if customized printing or size , shape will take sample making cost .
