13.56Mhz CR80 DESFire EV2 2/4/8K High Security NFC Cards

MIFARE DESFire EV2 is the latest addition to the MIFARE DESFire product family . it is common criteria EAL5+ security certified which is the same security certification level as demand for samrt card

IC products ,e.g ., for banking cards or electronic passports . It is also fully compatible with existing NFC Reader hardware platform . We can provide customer full color printing NXP DESFire EV2 2K

4K , 8K chip cards and with glossy , matt or frosted finished .  high security and speed data transmit features  can make we use them for event tickting ,hospitality , micro-payment , secure access

management , student ID , road tolling and parking .etc .

Features overview

RF interface: ISO/IEC 14443 Type A

• Contactless interface compliant with ISO/IEC 14443-2/3 A

• Low Hmin enabling operating distance up to 100 mm (depending on power provided by the PCD and antenna geometry)

• Fast data transfer: 106 kbit/s, 212 kbit/s, 424 kbit/s, 848 kbit/s

• 7 bytes unique identifier (option for Random ID)

• Uses ISO/IEC 14443-4 transmission protocol

• Configurable FSCI to support up to 128 bytes (256 bytes for 16 and 32 kB) frame size

Non-volatile memory

• 2 kB, 4 kB, 8 kB, 16 kB or 32 kB NV • Data retention of 25 years

• Write endurance typical 500 000 cycles

• Fast programming cycles (erase/write)

Security

• Common Criteria certification: EAL5+ (Hardware and Software)

• Unique 7 bytes serial number for each device

• Optional "RANDOM" ID for enhance security and privacy

• Mutual three-pass authentication

• Mutual authentication according to ISO/IEC 7816-4

• Flexible key management: 1 card master key and up to 14 keys per application

• Hardware DES using 56/112/168 bit keys featuring key version

• Hardware AES using 128-bit keys featuring key version

• Data authenticity by 8 byte CMAC

• Data encryption on RF-channel

• Authentication on application level

• Hardware exception sensors

• Self-securing file system

• Backward compatibility to MF3ICD40: 4 byte MAC, CRC 16

New features on MIFARE DESFire EV2

• MIsmartApp (Delegated Application Management)

• Memory reuse in DAM applications (Format Application)

• Transaction MAC on application level

• Multiple Key Sets per application with fast key rolling mechanism (up to 16 sets)

• Accessing files from any two applications during a single transaction

• Multiple keys assignments for each file access right (up to 8)

• Virtual Card Architecture for enhanced card/application selection on multi-VC devices with privacy protection • Proximity Check for protection against Relay Attacks

• Originality Check for proof of genuine NXP’s product

• New EV2 Secure Messaging based on AES (similar with MIFARE Plus’s secure messaging)

Applications

Secure public transport ticketing

• Multi-application smart city and mobility card

 • Secure access management

• Micro-payment and Loyalty

• Student ID

• Road tolling and parking

• Hospitality

• Event ticketing
