F8010

1. Features

RFinterface

Contactlesstransmissionofdataandsupply(nobatteryneeded)

Operatingfrequency:13.56MHz

Fastcommunicationbaudrate:106Kbit/s

Contactlesstransmissionofdataandsupply(nobatteryneeded)

Operatingdistance:upto100mm(dependingonantennageometry)

Halfduplexcommunicationprotocolusinghandshake

Typicaltransactiontime: ＜100ms

Highdataintegrity:16-bitCRC,parity,bitcoding,bitcounting

Trueanticollision

7byteserialnumber(cascadelevel2accordingtoISO/IEC14443-3)

EEPROM

192bytesoftotalmemory,dividedin48pages(4byteseach)　

144bytesofuserr/wmemoryarea,dividedin36pages(4byteseach)　

Fieldprogrammableread-onlylockingfunctionperpageforfirst64bytes　

Fieldprogrammableread-onlylockingfunctionperblock　

32-bituserdefinableOne-TimeProgrammable(OTP)area　

16-bitcounter　

Highsecurity　

Anti-cloningsupportbyunique7-byteserialnumberforeachdevice　

32-bituserprogrammableOTParea　

Fieldprogrammableread-onlylockingfunctionperpageforfirst512bits　

Read-onlylockingperblockforrestofmemory

TripleDataEncryptionStandard(3DES)

HighReliability

Endurance:100,000cycle

DataRetention:10Years

CascadedUID

TheanticollisionfunctionisbasedonanICindividualserialnumbercalled Unique IDentifier.TheUIDoftheFJ8010is7byteslongandsupportscascadelevel2 accordingtoISO/IEC14443-3.

Anticollision

AnintelligentanticollisionfunctionaccordingtoISO/IEC14443allowstooperate morethanonecardinthefieldsimultaneously.Theanticollisionalgorithm selectseachcardindividuallyandensuresthattheexecutionofatransactionwithaselectedcardisperformedcorrectlywithoutdatacorruptionresultingfromothercardsinthefield.
